CNC Machine LED Work Light ONN-M9K 2 Year Warranty Easy Installation Adjustable Bracket for EDM Engraving Machine
Product Overview
Fully sealed linear industrial lamp with aluminum & stainless steel housing, tempered shockproof glass lens, IP67 full waterproof/dustproof rating. Equipped low-decay 5730 LEDs, adjustable bracket with 70° left-right rotation. AC/DC12-24V wide voltage, multiple lengths & power options, 2 standard color temperatures, PF=1.0 constant power, long 50,000-hour lifespan for CNC and machining equipment, 18-month warranty.
Quick Detail
- Housing: Oxidized aluminum + stainless steel, tempered glass, IP67
- Light source: 5730 SMD LED, 120° beam angle, CRI Ra＞80
- Voltage: AC/DC12-24V wide input, PF=1.0
- CCT options: 6000-6500K cool white / 4000-4500K neutral white
- Sizes & power: 200(5W)/300(10W)/400(12W)/600(18W)/800(24W)/1000(30W)
- Mount: Φ5 screw bracket, 70° horizontal adjustable
- Standard cable: 0.5m, surface temp ≤60℃
- Lifespan: 50,000H
- Environment: Operate -20~45℃, store -40~70℃, humidity 10%–90%
Specifications
| Parameter |
Specification |
| Model |
ONN-M9K |
| Input Voltage |
AC/DC 12–24V |
| Optional Sizes & Power |
200mm(5W)~1000mm(30W) |
| CCT |
6000-6500K / 4000-4500K |
| CRI |
Ra＞80 |
| Beam Angle |
120° |
| IP Rating |
IP67 fully sealed |
| LED Chip |
5730 SMD |
| Power Factor |
PF=1.0 |
| Max Surface Temp |
≤60℃ |
| Adjust Range |
Bracket 70° left-right rotation |
| Mounting |
Φ5 screw fixing bracket |
| LED Lifetime |
50,000H |
| Operating Temp |
-20℃ ~ +45℃ |
Competitive Advantages
- Full IP67 hermetic sealing, resistant to cutting fluid, water splash and workshop dust
- Aluminum stainless alloy body delivers outstanding heat dissipation & corrosion resistance
- Impact-resistant tempered glass improves durability in harsh machine workshop
- 70° adjustable bracket realizes flexible lighting angle for machining areas
- Wide AC/DC 12-24V universal voltage adapts all industrial power supplies
- Multiple length/power options match different CNC machine cavity sizes
Applications
CNC machining centers, SMT lines, automated packaging, injection molding, robotics workcells, conveyors, and industrial warning systems.
Package Info
12–24pcs per carton, single N.W.0.29–1.57kg
